32′ Custom Enclosed Gooseneck Trailer

See details on this 32 ft Gooseneck Cargo Trailer, and request a quote today — we’ll customize it to fit your exact needs.

This steel chassis with aluminum frame enclosed custom gooseneck cargo trailer was built for all your large cargo transportation needs. Trailer options include 7K Dexter axles, Advantech floors, plywood walls, aerodynamic tapered nose, .030 screwless exterior skin, and more – complete this quality and iconic ATC look. Available in sizes from 28 ft to 53 ft, with thousands of options and layouts. Upgrade to an all-aluminum frame for an additional $3,600! This gooseneck cargo trailer is 8.5 x 32 ft, empty weight is 6,318 lbs, with a 8,082 lb load capacity and 14,400 GVWR. More trailer specifications are detailed below. To easily print these specs, click here.

Every trailer we make can be built with the color, frame, generator, flooring, etc. that you choose: see a complete list of trailer options.

For price tags, simply fill out our Quote Request Form and we’ll send a quote your way.

TRAILER SPECIFICATIONS

FRAME, AXLES, WHEELS
32′ OVERALL LENGTH – 8’8″ UPPER DECK LENGTH, 23’4″ LOWER DECK LENGTH
FULL PERIMETER STEEL FRAME PAINTED AND UNDERCOATED
(2) 6000# ELECTRIC BRAKE TORSION AXLES
SUPER SPREAD AXLES FOR WEIGHT DISTRIBUTION
2-5/16″ GOOSENECK COUPLER AND 7-WAY ELECTRICAL PLUG
FLOOR DESIGN – BEAVERTAIL
7′ INTERIOR HEIGHT
ALL TUBE WALL CONSTRUCTION ON 16″ CENTERS – 1″ X 1.5″
ALL TUBE CEILING CONSTRUCTION ON 16″ CENTERS – 1″ X 3″
8″ MAINFRAME – FLOOR CROSS MEMBERS 16″ ON CENTER
REAR SKID PLATES
ST235/80R 16″ LOAD RANGE E RADIAL TIRES
INTERIOR
FLOORING – 3/4″ ADVANTECH
3/8″ PLYWOOD WALLS
14″X14″ ROOF VENT
SPRING ASSIST RAMP COVER
(4) 5,000# D-RINGS
(3) LED DOME LIGHTS W/ WALL SWITCH
EXTERIOR
BONDED SCREW LESS ALUMINUM WHITE WALLS
1 PIECE ALUMINUM ROOF
ALL LED CLEARANCE LIGHTS AND BRAKE LIGHTS
ATP FRONT STONE GUARD
STAINLESS STEEL FRONT VERTICALS WITH CAST CORNERS
4,000# REAR RAMP DOOR W/ TRANSITION FLAP
36″ FLUSH LOCK SIDE DOOR
36″ ALUMINUM SLIDE OUT STEP

Still have a question? Call us at +1 (866) 545-3065, Email us or simply fill out our Contact Form.
